The range of Vicon semi-mounted cultivators is available with 3 configurations for the adjustment to the individual requirements.

Config. 3 rows, inter-tine spacing 330mm: large row and inter-tine spacing, available with front discs. For larger amounts of residue.

Config. 3 rows, inter-tine spacing 270mm: large row spacing, compatible with front discs, perfect for universal application.
Config. 4 rows, inter-tine spacing 200mm: reduced row and tine spacing.

The equipment possibilities of the Vicon Rau Tinetiller TR/TS are as versatile as your demands, with a choice of different implement combinations and variants Vicon Rau offer the possibility to equip the Tinetiller TR/TS to meet your individual needs.

The Vicon Rau Tinetiller TR/TS offers total flexibility with:

3 possible tine spacings
2 tine variants
8 types of shares
Front Cutting or Mixing discs
4 types of levelling devices
4 types of rear roller

This ensuring optimum mixing and intensive cultivation. A maximum working depth of 30cm is possible.

The Advantages:

Under beam clearance 830 and 870mm and tine spacing up to 330mm for blockage free operation
3 or 4 rows of tines on the same frame possible
Fantastic hollow tine technology with high vibration, flexibility and low power consumption
Wide range of shares available to cope with all soil conditions
Large choice of rear accessories under a parallelogram able to leave a rough and weather proof top layer up to a fine seedbed
Stubble cultivation and loosening from 5 to 35cm working depth

Model	Working width (m)	No. of rows	Power requirement Min./Max. HP
Tinetiller TR/TS 400	4.0	3 (spacing 270 or 330mm) or 4 (spacing 200mm)	145 / 280
Tinetiller TR/TS 500	5.0	3 (spacing 270 or 330mm) or 4 (spacing 200mm)	175 / 320
Tinetiller TR/TS 600	6.0	3 (spacing 270 or 330mm) or 4 (spacing 200mm)	205 / 360
